Kenworth Airglide 100 Replacement Parts

Click to enlarge.

Quality aftermarket replacement parts for Kenworth Airglide 100 AG100 Truck Suspensions.

Click here to down a PDF catalog version of this page with drawing and parts list.

KEY	OUR P/N	MACH #	OEM #	DESCRIPTION	QTY
1	-	-	K195-375; 925031	Torque Arm, 24" Center-to-Center, Includes Bushings	2
1	-	-	925150	Torque Arm, 25" Center-to-Center, Includes Bushings	2
2	-	-	K195-376; 944270	Torque Arm, 24" Center-to-Center, Includes Straddle	2
2	-	-	K195-376; 944270	Mount Bushing and Tapered Stud Bushing	2
3	KW9B	G-10303	836940	Torque Arm & Stabilizer Rod Bushing, Rubber, Straddle Mount	8
	HE9I	-	227720	Torque Arm & Stabilizer Rod Bushing, Rubber, Straddle Mount	8
	HE9I-U	-	-	Torque Arm & Stabilizer Rod Bushing, Poly, Straddle Mount	8
	HE9I-A	-	227722	Torque Arm Bushing, Straddle Mount, Aluminum Pin	8
4	HE9E	-	229610	Torque Arm Bushing, Rubber, Tapered Stud	2
4	HE9E-U	-	-	Torque Arm Bushing, Poly, Tapered Stud	2
5	KW10I	-	K048-449	Aluminum Air Spring Bracket	8
	KW10O		K048-449	Fabricated Steel Air Spring Bracket	8
	KW10P		K221-3057	Aluminum Air Spring Spacer	8
6	AS9422	-	K303-6;K303-14;	Firestone Air Spring to 1994	8
	AS1R11028		K303-15	Goodyear Air Spring to 1994
	AS64255			Continental Contitech Air Spring to 1994
	AS73568			Contitech Prime-Ride Air Spring to 1994
	AS9616	-	K303-16	Firestone Air Spring with Bracket, 1995 and up	8
	AS1R11242			Goodyear Air Spring with Bracket, 1995 and up
	AS64256			Continental ContiTech Air Spring with Bracket, 1995 and up
7	KW9C	G-4669	K066-58;	Stabilizer Bushing, Rubber	4
	KW9C	G-4669	K066-50	Stabilizer Bushing, Rubber	4
	KW9C-U	-	K066-449	Stabilizer Bushing, Poly	4
8	KW7C	-	K071-304	Stabilizer Bar Mounting Cap	4
9	-	-	K041-724-260P	Stabilizer Bar Mounting Bolt, Top of Bracket, M20-2.5 X 260mm Long	4
10	-	-	K041-717-160P	Stabilizer Bar Mounting Bolt, Bottom of Bracket, M16-2.0 X 160mm Long	4
11	-	-	K041-712-260P	Stabilizer Bar Mounting Bolt for Cast Center Bracket, M16-2.0 X 260mm Long	8
12	-	-	-	Washer for 16mm bolt	As Required
12	-	-	-	Washer for 20mm bolt	-
13	-	-	-	Lock Nut, M16-2.0	As Required
13	-	-	-	Lock Nut, M20-2.5 mm	-
14	-	-	-	Stabilizer Block Mounting Bolt, M16-2.0 X 170mm Long, Fabricated Hanger Bracket	6
15	-	-	K041-712-130P	Stabilizer End Mounting Bolt, M16X2.0 X 120mm	8
15	-	-	K041-712-150P	Stabilizer End Mounting Bolt, M16X2.0 X 150mm	8
16	SH85310	-	K374-87	Shock Absorber	4
	SH89423	-	K374-7, K374-9,	Shock Absorber, Premium Adjustable	4
	SH89423	-	K374-29	Shock Absorber, Premium Adjustable	4
17	KW9H-U	-	CA368-6	Shock Bushing, Poly, For Stud Mounted Shocks	16
18	-	-	H00500C	Universal Height Control Valve, Hadley Model 500, Apply Air To Dump	1
18	-	-	H01501UD	Universal Height Control Valve, Hadley Next Gen, Apply Air To Dump	1
19	-	-	-	Universal Linkage Kit	1
20	-	-	49NE2012	Torque Arm Mounting Nut For Tapered Pin Bushing	2
21	-	-	-	Torque Arm Washer, 1 5/16" ID	2
22	-	-	K21-922-3	Alignment Shim, 1/8" Thick	As Required
23	KW7B	-	K197-2943	Stablizer Bar Bracket	2
24	KW7A	G-10766	K272-145	Center Support Bracket, Fabricated Models to 1994	2
24	KW7D	G-10766	K272-145	Aluminum Center Support Bracket, Cast Models to 1994	2

Kenworth 227720 Polyurethane Torque Arm & Stabilizer Bushing

$47.72

In Stock

(0)

Add To Cart

Kenworth 229610 3" Taper Stud Rubber Torque Arm Bushing

$51.08

In Stock

(0)

Add To Cart

Kenworth 229610 3" Taper Stud Polyurethane Torque Arm Bushing

$85.89

In Stock

(0)

Add To Cart

Kenworth K272-145 Fabricated Drive Axle Center Hanger

$299.15

In Stock

(0)

Add To Cart

Kenworth K274-184 Cast Aluminum Drive Axle Center Hanger

$700.82

In Stock

(0)

Add To Cart

Kenworth K048-449 Cast Aluminum Air Spring Bracket

$44.51

In Stock

(0)

Add To Cart

Kenworth K048-449 Fabricated Steel Air Spring Bracket

$44.39

In Stock

(0)

Add To Cart

Kenworth K197-2943 Stabilizer Bar Bracket

$347.38

In Stock

(0)

Add To Cart

Kenworth K066-58 Rubber Stabilizer Bar Bushing

$10.30

In Stock

(0)

Add To Cart

Kenworth K066-449 Polyurethane Stabilizer Bar Bushing

$17.81

In Stock

(0)

Add To Cart

Kenworth K071-304 Stabilizer Bar Bracket Cap

$40.88

In Stock

(0)

Add To Cart

Kenworth Airglide 100 Torque Arm Bolt Kit

$7.95

In Stock

(0)

Add To Cart

1 2 3 Next Page View All
